The EA888 Gen2 2.0L is a 2.0-liter turbocharged direct-injection gasoline engine (TFSI / TSI) from the Volkswagen-Audi Group’s second-generation EA888 series.
It entered mass production in 2008 and remained in production until approximately 2015; it is an improved version based on the first-generation EA888.
Key improvements included: reducing the diameter of the crankshaft main bearings to minimize friction, adopting a variable-displacement
oil pump, optimizing the piston ring set, adding the Audi Valvelift System (AVS) variable valve lift system to select high-output versions,
and meeting Euro 5 emissions standards. This engine was widely used in numerous models from Audi, Volkswagen, Škoda, and SEAT.
We recommend providing a clear VIN to ensure the accuracy of the engine code.
Our products are exported to various parts of the country, and the customers we have worked with have received unanimous praise.
The company has invested over 20 million yuan in high-end remanufacturing equipment imported from abroad and a first-class production
team in the country. Our warehouse has a total area of over 8000 square meters, with scientific management and sufficient supply of goods.
| Specification | Details |
|---|---|
| Engine Manufacturer | Volkswagen Group / Audi |
| Engine Family | EA888 Gen 2 |
| Displacement | 1984cc |
| Cylinder Configuration | Inline 4-Cylinder |
| Number of Cylinders | 4 |
| Number of Valves | 16 |
| Valvetrain | DOHC |
| Bore | 82.5 mm |
| Stroke | 92.8 mm |
| Compression Ratio | Commonly 9.6:1, depending on engine code |
| Fuel Type | Gasoline / Petrol |
| Aspiration | Turbocharged |
| Maximum Power | Approximately 147–155 kW, depending on engine code |
| Maximum Torque | Commonly 280 Nm |
| Timing System | Timing Chain |
| Cylinder Block Material | Cast Iron |
| Cylinder Head Material | Aluminum Alloy |
Technical specifications vary according to engine code, production year, market and ECU calibration.
Please confirm the original engine code before ordering.
The EA888 Gen 2 family covers different engine configurations and vehicle platforms.
Common applications include:
| Vehicle Model | Chassis | Common Engine Codes |
|---|---|---|
| Audi A4 2.0 TFSI | B8 / 8K | CAEB / CDNC / CDNB |
| Audi A4 Avant 2.0 TFSI | B8 / 8K5 | CAEB / CDNC |
| Audi A5 2.0 TFSI | 8T / 8F | CAEB / CDNC / CDNB |
| Audi Q5 2.0 TFSI | 8R | CAEB / CDNC |
| Vehicle Model | Chassis | Common Engine Codes |
|---|---|---|
| Volkswagen Golf GTI 2.0 TSI | Golf VI / 5K | CCTA / CCZB |
| Volkswagen Tiguan 2.0 TSI | 5N | CAWA / CCZC / CCTA |
| Volkswagen Scirocco 2.0 TSI | 13 | CCZA / CCZB |
| Volkswagen Passat 2.0 TSI | B6 / B7 | CCTA / CCZA, application dependent |
| Volkswagen CC 2.0 TSI | 35 / B6 | CCTA / CCZA, application dependent |
| Volkswagen Jetta 2.0 TSI | A5 / A6 | CCTA / CBFA, application dependent |
Other Volkswagen Group applications may include selected SEAT and Škoda models.
Important Fitment Notice:
The above vehicle list is for reference only. Engine compatibility depends on the original engine code,
production date, mounting orientation, transmission, drivetrain and vehicle market.
Longitudinal engines such as CAEB and CDNC should not automatically be considered interchangeable
with transverse engines such as CCTA, CCZA or CCZB.
Please provide your VIN, original engine code and OE reference number before ordering.
The EA888 Gen 2 engine family uses different engine assembly and component part numbers according
to engine code and vehicle application.
Common parts catalog prefixes include 06H and 06J. These prefixes are not complete engine long block part numbers.
Some related timing system component references include:
06H109158J – Timing chain component
06H109158H – Timing chain component
06H109509Q – Timing chain guide
06H109469AP – Timing chain guide
06H109469T – Timing chain guide
06H109467AE – Timing chain tensioner
06H115225L – Oil pump chain
06H109507M – Oil pump chain tensioner
06H100033, 06H100033X, 06H100035, 06H100035X– Engine Assembly / Long Block
06H103011, 06H103011AN – Short Block / Cylinder Block
These are component references and should not be used as complete engine assembly numbers.
For an accurate engine long block reference, please confirm the original engine code, VIN and OE engine assembly number.
The long block assembly generally includes the main engine structure and internal mechanical components.
Depending on the actual product configuration, it may include:
Cast iron cylinder block
Aluminum alloy cylinder head
Crankshaft
Pistons and piston rings
Connecting rods
Main bearings and connecting rod bearings
Camshafts
Intake and exhaust valves
Valve springs and valvetrain components
Timing chain components
Oil pan
Oil Pump
Items Not Automatically Included:
Unless specifically confirmed in the quotation, the long block does not necessarily include:
Turbocharger
Intake manifold and throttle body
High-pressure fuel pump and fuel injectors
ECU and engine wiring harness
Alternator and starter motor
Air conditioning compressor
Exhaust manifold and catalytic converter
External coolant pipes and accessories
Other external engine components
Please request the detailed BOM, product photographs and packing list before order confirmation.
We support international B2B customers looking for
Volkswagen and Audi EA888 engine long blocks and replacement engine solutions.
Our potential business partners include:
Automotive engine importers
Engine parts distributors
Wholesale engine suppliers
Professional engine rebuilding companies
Automotive repair workshops
Replacement engine dealers
B2B support can be arranged according to order requirements:
Wholesale and bulk order inquiries
Engine code and OE number verification
Vehicle fitment assistance
Long block configuration confirmation
Product photographs and packing details
Export packing arrangements
Shipping coordination
Order documentation according to the actual supply arrangement
For bulk orders, please contact our sales team for availability, lead time, packing details and wholesale quotation.
Q1: What is the Volkswagen Audi EA888 Gen 2 engine?
The EA888 Gen 2 is a second-generation version of Volkswagen Group's turbocharged direct-injection
gasoline engine family. It includes different 1.8L and 2.0L configurations.
Q2: What is the displacement of the EA888 Gen 2 2.0T engine?
The common 2.0T version has a displacement of 1,984cc.
Q3: Which vehicles use the EA888 Gen 2 2.0T engine?
Selected Audi A4, A5 and Q5 models, as well as Volkswagen Golf GTI, Tiguan, Passat, Scirocco
and CC models, use different EA888 engine codes.
Q4: Are CAEB, CCTA, CCZA and CDNC interchangeable?
Not automatically. These engines may differ in mounting orientation, cylinder head configuration,
AVS equipment, fuel system, accessories and vehicle applications. Original engine code and OE verification are required.
Q5: What material is the EA888 Gen 2 cylinder block made of?
The common EA888 Gen 2 2.0T engine uses a gray cast iron cylinder block and an aluminum alloy cylinder head.
Q6: Does the long block include the turbocharger and fuel injection system?
Not necessarily. Turbocharger, fuel injectors, high-pressure fuel pump, ECU, wiring harness
and external accessories are generally separate unless specifically listed in the quotation.
Q7: How can I confirm the correct engine long block?
Please provide your vehicle VIN, original engine code, production year and original OE reference number.
This information helps verify the correct engine configuration.
Are you looking for a Volkswagen Audi EA888 Gen 2 2.0T TSI TFSI engine long block for your replacement engine business?
Contact us with your required engine code, quantity, destination country and original OE reference number.
Our sales team can assist with application verification, product configuration, wholesale pricing and export arrangements.
Contact us today for EA888 Gen 2 engine availability and B2B quotation.
| Place of Origin | Guangdong, China |
| Condition | New |
| Purpose | for replace/repair |
| Type | Gas / Petrol Engine |
| Power | OEM Standards |
| Quantity (pieces) | 1 - 10 | 11 - 50 | > 50 |
| Lead time (days) | 7 | 15 | To be negotiated |
1. Our remanufactured products use accessories provided by well-known brand suppliers such as VICTORREINZ, SCHAEFFLER, KS KOLBENSCHMIDT GmbH, etc.
2. Our product quality is close to the original factory quality, but the price is only 50-60% of the original engine. We can also provide you with a one-year or 100000 kilometer warranty service for the entire machine, and professional after-sales personnel will follow up with you.
3. We have over 15 years of experience in the production and research of automotive engines, and our technical level and personnel training are very scientific and mature. Customers who have worked with us have expressed their agreement with our products and after-sales service.
4. 2018 It has achieved an annual production capacity of 2200 units and has become a major supplier of high-end engine remanufacturing and parts in China's automotive aftermarket.
5. In April 2021, T/CAAMTB passed the certification company of China Automobile Research and Huacheng. 19-2019 Certification of the management system requirements of gas vehicle parts remanufacturing enterprisesIn October 2021, he became a member of the National Green Manufacturing Technology Standardization Committee and participated in the drafting of the Technical Specification for Assembly of Remanufacturing Mechanical and Electrical Products.
