The Audi CJT is an early 3.0L mechanically supercharged V6 gasoline engine (3.0 TFSI) from the Volkswagen-Audi Group’s EA837 series,
primarily produced around 2010–2015. It was developed from the naturally aspirated 3.2 FSI V6 and was the first to feature the Eaton
supercharger (Roots-type compressor) on a large scale, delivering lag-free power delivery.
CJT is a key designation for the first-generation supercharged 3.0 TFSI, primarily used in the first-generation Audi Q7 (4L),
with the 272 horsepower version being the most common. The series also included higher-output tunings (up to 333 horsepower).
Featuring an all-aluminum V6 design, direct injection (FSI), and a DOHC 24-valve configuration, this engine is renowned for its linear acceleration
and instantaneous response, and stands as a representative example of Audi’s early supercharged six-cylinder powertrains.
Notice: Please provide your 17-digit VIN (Chassis Number) to double-check engine code and component compatibility before placing an order.
Our products are exported to various parts of the country, and the customers we have worked with have received unanimous praise.
The company has invested over 20 million yuan in high-end remanufacturing equipment imported from abroad and a first-class production
team in the country. Our warehouse has a total area of over 8000 square meters, with scientific management and sufficient supply of goods.
Brand: Audi / Volkswagen
Engine Code: CJT
Engine Family: EA837
Displacement: 3.0L / 2995cc
Engine Configuration: 90-degree V6
Fuel Type: Gasoline / Petrol
Fuel Injection: FSI Direct Injection
Aspiration: Eaton Roots-Type Supercharged
Valve Configuration: DOHC, 24 Valves
Bore × Stroke: 84.5 × 89.0 mm
Compression Ratio: Approximately 10.5:1
Reference Maximum Power: 200 kW / 272 hp
Reference Maximum Torque: Approximately 400 Nm
Cooling System: Water-Cooled
Installation: Longitudinal
Emission Standard: Euro 5
Product Type: Engine Long Block
Specifications refer to the CJT 200 kW reference version.
Other EA837 engine codes and output versions may have different specifications.
The CJT engine is associated with selected Audi 3.0 TFSI applications.
Potential vehicle applications include:
Audi Q7 3.0 TFSI quattro – 4L
Audi Q5 3.0 TFSI quattro – 8R
Audi A6 3.0 TFSI quattro – C7 / 4G
Audi A6L 3.0 TFSI – selected market versions
Audi A7 Sportback 3.0 TFSI – 4G
Audi A8 / A8L 3.0 TFSI – D4 / 4H
Selected Audi S4 and S5 3.0 TFSI applications
Fitment Notice
The above applications are reference applications, not a universal compatibility guarantee.
Different vehicle years and market versions may use different engine codes, power outputs, engine mounting configurations and original part numbers.
Please provide your VIN, original engine code, vehicle model year and engine photos before ordering. We recommend confirming compatibility before shipment.
The following numbers are listed as supplier reference numbers for selected CJT 3.0 TFSI engine assemblies:
06E100032G / 06E 100 032 G
06E100032GX (Remanufactured / Exchange Engine)
06E100035C / 06E 100 035 C
06E100035CX
06E100031M / 06E 100 031 M
Short Block Reference:
06E103011 / 06E 103 011
Engine Codes / Cross Reference :
CJT, CJTA, CJTB, CJTC, CJED, CJEE, EA837 Gen2, Audi 3.0 Supercharged
These references may represent different engine assembly, exchange-engine or short-block configurations.
They should not be treated as universal interchangeable long block numbers.
Please provide your VIN and original engine identification information for accurate OEM part-number verification.
The long block assembly may include the following major internal engine components, depending on the actual product configuration:
Aluminum alloy engine block
Left and right cylinder heads
Crankshaft
Connecting rods
Pistons and piston rings
Intake and exhaust camshafts
Intake and exhaust valves
Valve springs
Main bearings
Connecting rod bearings
Timing chain components
Related internal engine components
Configuration Notice
The exact component list depends on the actual product BOM.
The Eaton supercharger, intake manifold, fuel injectors, high-pressure fuel pump, fuel rails,
throttle body, alternator, starter motor, ECU, wiring harness and other external accessories
are not included unless specifically confirmed in the quotation.
Our Audi CJT 3.0 TFSI engine supply is intended for professional automotive businesses, including:
Automotive engine importers
Engine wholesalers and distributors
Automotive repair workshops
Engine rebuilding companies
Auto parts trading companies
Regional replacement-engine suppliers
We support product identification, engine specification confirmation, fitment checking,
wholesale quotations and export packing arrangements.
Q1: What is the displacement of the Audi CJT engine?
The Audi CJT engine has a displacement of 2,995cc, commonly referred to as a 3.0L V6 gasoline engine.
Q2: Is the Audi CJT 3.0T engine turbocharged or supercharged?
The CJT uses a mechanically driven Eaton Roots-type supercharger rather than a conventional exhaust-driven turbocharger.
Q3: What is the power output of the Audi CJT engine?
The commonly listed CJT base version produces approximately 200 kW / 272 hp and 400 Nm of torque.
Other EA837 variants have different output ratings.
Q4: Which Audi vehicles use the CJT engine?
Selected Audi Q7, Q5, A6, A7 and A8 3.0 TFSI applications are listed in supplier fitment references.
Exact compatibility must be verified using the original engine code and VIN.
Q5: Does the long block include the supercharger?
A standard long block focuses on the main internal engine assembly.
The supercharger and external accessories are not included unless specifically stated in the quotation.
Q6: How can I confirm the correct engine for my vehicle?
Please provide your VIN, original engine code, vehicle year and photos of your original engine.
These details help verify the correct engine configuration.
Q7: Can you supply CJT engines for wholesale orders?
Please contact us with your required quantity, destination country
and engine specifications for product availability and a wholesale quotation.
Looking for an Audi CJT 3.0L V6 TFSI supercharged engine long block?
Contact our sales team with your original engine code, VIN, required quantity and destination country.
We welcome inquiries from international engine importers, wholesalers, distributors, engine rebuilders and automotive repair businesses.
Request product specifications, fitment assistance and an export quotation for your business.
| Place of Origin | Guangdong, China |
| Condition | New |
| Purpose | for replace/repair |
| Type | Gas / Petrol Engine |
| Power | OEM Standards |
| Quantity (pieces) | 1 - 10 | 11 - 50 | > 50 |
| Lead time (days) | 7 | 15 | To be negotiated |
