The Audi CAL / CALA is a late-generation 3.2L naturally aspirated V6 gasoline engine from the Volkswagen-Audi Group’s EA837 series (actual displacement: 3,197 cc, commonly referred to as the 3.2 FSI). It is an upgraded version of the early 3.2 FSI engines (such as the AUK and BKH) and was produced from approximately 2007 to 2012.
Key improvements include a larger bore (85.5 mm), the introduction of the Audi Valvelift System (AVS, variable valve lift), optimized variable valve timing, and intake manifold switching, while continuing to feature an all-aluminum construction and direct injection (FSI). Offering greater power and better responsiveness, it served as the primary naturally aspirated six-cylinder powerplant for models on the Audi B8 platform (A4, A5) and the Q5, among others, and also acted as a technical bridge to the subsequent mechanically supercharged 3.0 TFSI.
Our products are exported to various parts of the country, and the customers we have worked with have received unanimous praise. The company has invested over 20 million yuan in high-end remanufacturing equipment imported from abroad and a first-class production team in the country. Our warehouse has a total area of over 8000 square meters, with scientific management and sufficient supply of goods.
Specifications:
Engine Code: CAL / CALA (related codes: CALB, etc.)
Displacement: 3197 cc (nominal 3.2L)
Cylinder Configuration: V6 (90°)
Bore × Stroke: 85.5 mm × 92.8 mm
Compression Ratio: 12.5:1
Valve Train: DOHC, 4 valves per cylinder (24 valves total) + AVS variable valve lift + variable valve timing
Maximum Power: 195 kW (265 horsepower) @ 6,500 rpm
Maximum Torque: 330 Nm @ approx. 3,000–5,000 rpm
Emissions Standards: Euro 4 / Euro 5
| Model Number | CAL 3.2 |
Fitment / Compatible Vehicles:
CAL / CALA / CALB are primarily used on Audi’s longitudinally mounted MLB platform for mainstream midsize and full-size models:
Audi A4 / A4 Quattro (B8 / 8K): 3.2 FSI (2007–2012)
Audi A5 / A5 Coupe / Cabriolet (8T / 8F): 3.2 FSI (2007–2012)
Audi Q5 (8R): 3.2 FSI quattro (2008–2012)
Audi A6 / A6 Quattro (C6 / 4F Facelift): 3.2 FSI (2008–2011)
OE/OEM Part Numbers:
Engine Assembly / Complete Engine:
06E100031R / 06E 100 031 R
06E100031RX (Remanufactured / Exchange Engine)
06E100031H / 06E 100 031 H
06E100032A / 06E 100 032 A
Short Block:
06E103011 / 06E 103 011
Engine Codes / Cross Reference:
CAL, CALA, CALB, Audi 3.2 FSI, Audi 3.2 V6 Engine, AVS
| Place of Origin | Guangdong, China |
| Condition | New |
| Purpose | for replace/repair |
| Type | Gas / Petrol Engine |
| Power | OEM Standards |
| Quantity (pieces) | 1 - 10 | 11 - 50 | > 50 |
| Lead time (days) | 7 | 15 | To be negotiated |
1. Our remanufactured products use accessories provided by well-known brand suppliers such as VICTORREINZ, SCHAEFFLER, KS KOLBENSCHMIDT GmbH, etc.
2. Our product quality is close to the original factory quality, but the price is only 50-60% of the original engine. We can also provide you with a one-year or 100000 kilometer warranty service for the entire machine, and professional after-sales personnel will follow up with you.
3. We have over 15 years of experience in the production and research of automotive engines, and our technical level and personnel training are very scientific and mature. Customers who have worked with us have expressed their agreement with our products and after-sales service.
4. 2018 It has achieved an annual production capacity of 2200 units and has become a major supplier of high-end engine remanufacturing and parts in China's automotive aftermarket.
5. In April 2021, T/CAAMTB passed the certification company of China Automobile Research and Huacheng. 19-2019 Certification of the management system requirements of gas vehicle parts remanufacturing enterprisesIn October 2021, he became a member of the National Green Manufacturing Technology Standardization Committee and participated in the drafting of the Technical Specification for Assembly of Remanufacturing Mechanical and Electrical Products.
