The Land Rover 508PS engine belongs to the third generation (internal code AJ133) of Jaguar Land Rover’s renowned AJ-V8 engine family. This series was introduced in 2009 to fully replace the earlier
4.2L and 4.4L V8 engines. “508PS” is the engine code used within the Jaguar Land Rover system, where 50 stands for 5.0 liters, 8 for a V8 configuration, P for Petrol (gasoline), and S for Supercharged
(mechanical supercharger). (Note: The naturally aspirated version is coded 508PN.)
Technical Features and Construction: It features a lightweight, high-pressure die-cast all-aluminum cylinder block and head, and is equipped with a centrally mounted high-pressure direct injection system (SGDI),
dual independent variable camshaft timing (DIVCT), and a sixth-generation Eaton TVS Roots-type twin-scroll supercharger located within the V-angle.
Our products are exported to various parts of the country, and the customers we have worked with have received unanimous praise. The company has invested over 20 million yuan in high-end remanufacturing equipment imported from abroad and a first-class production team in the country. Our warehouse has a total area of over 8000 square meters, with scientific management and sufficient supply of goods.
Technical Specifications:
Engine Code: 508PS / AJ133 SC
Engine Family: JLR AJ-V8 Gen III
Displacement: “5,000 cc (5.0 L)”
Cylinder Configuration: 90° V-8 (V8)
Bore × Stroke: 92.5 mm × 93.0 mm
Compression Ratio: 9.5 : 1
Maximum Power Output: 375 kW – 423 kW (510 HP – 575 HP), depending on vehicle model tuning
Peak Torque: “625 N·m – 700 N·m @ 2,500–5,500 RPM”
Intake/Supercharging System: “Eaton TVS 6th-generation mechanical supercharger, twin intercoolers”
Valve Train/Fuel Injection System: “DOHC, 32V, DIVCT, direct injection”
Fitment / Compatibility:
Range Rover (L322 / L405) [5.0 V8 Supercharged / Autobiography] (2010–2022)
Range Rover Sport (L320 / L494) [5.0 V8 Supercharged / SVR] (2010–2022)
Land Rover Defender (L663) [5.0 V8] (2021–present)
(The same engine is also widely used in high-performance Jaguar models such as the XJ, XF, and F-Type)
OE Part Numbers:
Engine Long Block: LR010778, LR099516, LR111084, LR056340
Short Block: LR037000, LR044955
Engine Service Code: 508PS
| Model Number | 508PS |
| Place of Origin | Guangdong, China |
| Condition | New |
| Purpose | for replace/repair |
| Type | Gas / Petrol Engine |
| Power | OEM Standards |
| Quantity (pieces) | 1 - 10 | 11 - 50 | > 50 |
| Lead time (days) | 7 | 15 | To be negotiated |
1. Our remanufactured products use accessories provided by well-known brand suppliers such as VICTORREINZ, SCHAEFFLER, KS KOLBENSCHMIDT GmbH, etc.
2. Our product quality is close to the original factory quality, but the price is only 50-60% of the original engine. We can also provide you with a one-year or 100000 kilometer warranty service for the entire machine, and professional after-sales personnel will follow up with you.
3. We have over 15 years of experience in the production and research of automotive engines, and our technical level and personnel training are very scientific and mature. Customers who have worked with us have expressed their agreement with our products and after-sales service.
4. 2018 It has achieved an annual production capacity of 2200 units and has become a major supplier of high-end engine remanufacturing and parts in China's automotive aftermarket.
5. In April 2021, T/CAAMTB passed the certification company of China Automobile Research and Huacheng. 19-2019 Certification of the management system requirements of gas vehicle parts remanufacturing enterprisesIn October 2021, he became a member of the National Green Manufacturing Technology Standardization Committee and participated in the drafting of the Technical Specification for Assembly of Remanufacturing Mechanical and Electrical Products.
