What is engine assembly?The HR16DE is a 1.6L inline-four naturally aspirated engine from Nissan’s HR series (developed in collaboration with Renault; Renault’s code name is H4M).
It was introduced around 2005–2006 to replace earlier small-displacement engines such as the QG16. It features an all-aluminum block and an aluminum DOHC 16-valve cylinder head,
with chain-driven timing and C-VTC (Continuously Variable Valve Timing) on the intake side. The term “older models” primarily refers to early production batches
from around 2005–2012; later versions included upgrades to valve timing and control systems.
Our products are exported to various parts of the country, and the customers we have worked with have received unanimous praise. The company has invested over 20 million yuan in high-end remanufacturing equipment imported from abroad and a first-class production team in the country. Our warehouse has a total area of over 8000 square meters, with scientific management and sufficient supply of goods.
Technical Specifications:
Engine Code: HR16DE / HR16 (MPI multipoint fuel injection version)
Engine Displacement: 1.6 L (1598 cc / 97.5 cu. in.)
Cylinder Configuration: Inline-4 (I4)
Valve Train: DOHC (Dual Overhead Camshaft), 4 valves per cylinder (16 valves total), with C-VTC variable valve timing
Bore × Stroke: 78.0 mm × 83.6 mm
Compression Ratio: 9.8:1 – 10.7:1 (subject to slight adjustments based on regional specifications)
Material: High-strength, lightweight cast aluminum alloy
Intake/Fuel Delivery: Naturally Aspirated / Multi-Point Injection (MPI)
Vehicle Applications:
Nissan Tiida (C11): 2004–2012 (1.6L HR16DE)
Nissan Versa: 2007–2012 (1.6L HR16DE)
Nissan Note (E11): 2006–2013 (1.6L HR16DE)
Nissan Qashqai (J10 European/Overseas 1.6L Version): 2007–2013
Nissan Juke (F15 1.6L naturally aspirated version): 2010–2018
Nissan Micra / March (K12/K13 1.6L version): 2005–2015
Nissan NV200: (1.6L HR16DE models)
Nissan Bluebird Sylphy (G11 1.6L version): 2005–2012
Renault Duster / Logan / Sandero / Captur: (Some overseas markets are equipped with the same H4M 1.6L cylinder head)
Reference OE Numbers:Nissan OEM Part Numbers:
11040-EE000, 11040-EE00A, 11040-EE00B
11040-ED000, 11040-ED00A, 11040-ED00B
11040-BC200, 11040-ED025
1104A-WR60A
11040-3HC0A
11040-3HC5A
Other Related: 11040-EE00x Series
Note: There may be slight variations depending on the model year and vehicle model. We recommend verifying the casting number and the original vehicle part number.
| Model Number | Nissan HR old model |
| Place of Origin | Guangdong, China |
| Condition | New |
| Purpose | for replace/repair |
| Type | Gas / Petrol Engine |
| Power | OEM Standards |
| Quantity (pieces) | 1 - 10 | 11 - 50 | > 50 |
| Lead time (days) | 7 | 15 | To be negotiated |
1. Our remanufactured products use accessories provided by well-known brand suppliers such as VICTORREINZ, SCHAEFFLER, KS KOLBENSCHMIDT GmbH, etc.
2. Our product quality is close to the original factory quality, but the price is only 50-60% of the original engine. We can also provide you with a one-year or 100000 kilometer warranty service for the entire machine, and professional after-sales personnel will follow up with you.
3. We have over 15 years of experience in the production and research of automotive engines, and our technical level and personnel training are very scientific and mature. Customers who have worked with us have expressed their agreement with our products and after-sales service.
4. 2018 It has achieved an annual production capacity of 2200 units and has become a major supplier of high-end engine remanufacturing and parts in China's automotive aftermarket.
5. In April 2021, T/CAAMTB passed the certification company of China Automobile Research and Huacheng. 19-2019 Certification of the management system requirements of gas vehicle parts remanufacturing enterprisesIn October 2021, he became a member of the National Green Manufacturing Technology Standardization Committee and participated in the drafting of the Technical Specification for Assembly of Remanufacturing Mechanical and Electrical Products.
