What is engine assembly?The HR16DE is a 1.6L inline-four naturally aspirated engine from Nissan’s HR series (developed in collaboration with Renault; Renault code name: H4M). Major improvements to
the new version (which underwent gradual upgrades starting around 2010–2012 and was further optimized after 2017) include: the addition of dual C-VTC (variable valve timing
for both intake and exhaust), the adoption of a dual-injection system in some versions, and optimizations to the intake and exhaust systems as well as emissions control.
Compared to the older model, which featured variable valve timing on the intake side only, the new model offers significant improvements in power response, fuel economy,
and emissions, and is widely used in compact vehicles worldwide.
Our products are exported to various parts of the country, and the customers we have worked with have received unanimous praise. The company has invested over 20 million yuan in high-end remanufacturing equipment imported from abroad and a first-class production team in the country. Our warehouse has a total area of over 8000 square meters, with scientific management and sufficient supply of goods.
Technical Specifications:
Engine Code: HR16DE / HR16 (New Dual Injector / Twin C-VTC Version)
Engine Displacement: 1.6 L (1598 cc / 97.5 cu. in.)
Cylinder Configuration: Inline-4 (I4)
Valve Train: DOHC (Dual Overhead Camshaft), 4 valves per cylinder (16 valves total), with Twin C-VTC (Dual Variable Valve Timing for Intake and Exhaust)
Fuel Delivery: Dual Injector System
Bore × Stroke: 78.0 mm × 83.6 mm
Compression Ratio: 10.7:1 – 10.8:1
Material: High-strength, lightweight cast aluminum alloy
Intake Configuration: Naturally Aspirated
Vehicle Applications:
Nissan Sylphy / Sentra (Nissan Xuan Yi / Sentra B17 / B18): 2012–2020+ (New 1.6L HR16DE)
Nissan Tiida (Nissan Qida C12 / C13): 2011–2020+
Nissan Versa (N17 / N18): 2012–2020+
Nissan Sunny / Almera (N17 / N18): 2011–2020+
Nissan Kicks (P15): 2016–2020+ (1.6L HR16DE)
Nissan Note (E12): 2012–2020
Nissan Micra / March (K14): 2017–2020+
Renault Captur / Clio / Megane: (Some overseas models equipped with the same H4M/HR16 dual-injection cylinder head)
Reference OE Numbers:
Nissan OEM Part Numbers:
11040-3AV0A, 11040-3AV1A, 11040-3AV0B (Most typical part numbers for the new dual-injection HR16 cylinder heads)
11040-1HK0A, 11040-1HK0B
11040-3DB0A, 11040-5RA0A (commonly found on newer models, such as 2018+ Kicks / Versa)
11040-3HC0A / 11040-3HC5A
1104A-WR60A
Other related newer part numbers (must be verified based on specific model year and vehicle model)
Note: Newer and older cylinder heads are not interchangeable in terms of valve timing mechanisms; it is recommended to verify the vehicle’s casting number and part number.
| Model Number | Nissan HR16 HR15 new model |
| Place of Origin | Guangdong, China |
| Condition | Remanufactured |
| Purpose | for replace/repair |
| Type | Gas / Petrol Engine |
| Power | OEM Standards |
| Quantity (pieces) | 1 - 10 | 11 - 50 | > 50 |
| Lead time (days) | 7 | 15 | To be negotiated |
1. Our remanufactured products use accessories provided by well-known brand suppliers such as VICTORREINZ, SCHAEFFLER, KS KOLBENSCHMIDT GmbH, etc.
2. Our product quality is close to the original factory quality, but the price is only 50-60% of the original engine. We can also provide you with a one-year or 100000 kilometer warranty service for the entire machine, and professional after-sales personnel will follow up with you.
3. We have over 15 years of experience in the production and research of automotive engines, and our technical level and personnel training are very scientific and mature. Customers who have worked with us have expressed their agreement with our products and after-sales service.
4. 2018 It has achieved an annual production capacity of 2200 units and has become a major supplier of high-end engine remanufacturing and parts in China's automotive aftermarket.
5. In April 2021, T/CAAMTB passed the certification company of China Automobile Research and Huacheng. 19-2019 Certification of the management system requirements of gas vehicle parts remanufacturing enterprisesIn October 2021, he became a member of the National Green Manufacturing Technology Standardization Committee and participated in the drafting of the Technical Specification for Assembly of Remanufacturing Mechanical and Electrical Products.
