The 306PS older model (also known as the 30HD0D / AJ126) is an early version (approximately 2012–2017/2018) of the Land Rover/Jaguar 3.0L V6 mechanically supercharged gasoline engine,
and is a “truncated version” (derived from a V8 to a V6) of the AJ-V8 family.
It features an aluminum alloy cylinder block, equipped with an Eaton M112 supercharger, direct injection, and dual variable valve timing, and is renowned for its instantaneous response and
lack of turbo lag. Early versions were primarily used in models such as the Discovery 4 and Range Rover Sport; subsequent versions underwent minor updates (power calibration, ECU, etc.),
but the core structure of the cylinder block remained essentially the same.
Cylinder Block Material and Advanced Manufacturing Process:
Material: High-strength, lightweight, all-aluminum alloy die-cast cylinder block (Aluminum Alloy V6 Crankcase).
While significantly reducing the weight of traditional cast-iron engine blocks and improving front-axle weight distribution, it offers excellent rigidity against knocking and high-pressure detonation.
Inner Wall Treatment: The interior features high-precision honing to reinforce the inner walls or composite coating technology, providing excellent resistance to high temperatures anwear, as well as superior heat dissipation and thermal conductivity—perfectly suited for the high thermal load conditions of the 306 PS supercharged engine.
Our products are exported to various parts of the country, and the customers we have worked with have received unanimous praise. The company has invested over 20 million yuan in high-end remanufacturing equipment imported from abroad and a first-class production team in the country. Our warehouse has a total area of over 8000 square meters, with scientific management and sufficient supply of goods.
Specifications:
Displacement: 2995 cc (3.0L)
Cylinder Configuration: V6 (90° angle)
Bore × Stroke: 84.5 mm × 89.0 mm
Compression Ratio: 10.5:1
Cylinder Block Material: Aluminum Alloy
Emissions Standard: EURO 5
Compatible Models:
Land Rover Range Rover Sport (L494 3.0 SC, 2014–early 2018)
Land Rover Range Rover (L405 3.0 SC, 2013–2018)
Land Rover Discovery 4 & Discovery 5 (3.0 SC, 2014–2018)
Land Rover Range Rover Velar (3.0 SC, 2018–2020)
Jaguar (3.0L V6 supercharged models: XE, XF, XJ, F-Type, F-Pace)
(Please verify the engine code 306PS and VIN for confirmation.)
Engine Bare Block / Mid-Block Assembly Reference: LR062617, LR041639
Engine Assembly / Main Engine Swap Reference: LR079612, LR051390
| Model Number | 306PS |
| Place of Origin | Guangdong, China |
| Condition | New |
| Purpose | for replace/repair |
| Type | Gas / Petrol Engine |
| Power | OEM Standards |
| Quantity (pieces) | 1 - 10 | 11 - 50 | > 50 |
| Lead time (days) | 7 | 15 | To be negotiated |
1. Our remanufactured products use accessories provided by well-known brand suppliers such as VICTORREINZ, SCHAEFFLER, KS KOLBENSCHMIDT GmbH, etc.
2. Our product quality is close to the original factory quality, but the price is only 50-60% of the original engine. We can also provide you with a one-year or 100000 kilometer warranty service for the entire machine, and professional after-sales personnel will follow up with you.
3. We have over 15 years of experience in the production and research of automotive engines, and our technical level and personnel training are very scientific and mature. Customers who have worked with us have expressed their agreement with our products and after-sales service.
4. 2018 It has achieved an annual production capacity of 2200 units and has become a major supplier of high-end engine remanufacturing and parts in China's automotive aftermarket.
5. In April 2021, T/CAAMTB passed the certification company of China Automobile Research and Huacheng. 19-2019 Certification of the management system requirements of gas vehicle parts remanufacturing enterprisesIn October 2021, he became a member of the National Green Manufacturing Technology Standardization Committee and participated in the drafting of the Technical Specification for Assembly of Remanufacturing Mechanical and Electrical Products.
